- Size: 0.04
- Place of Origin: JINAN
- Brand Name: JINGLU
- Model Number: EQS
- Weight: 15.000 kg
I. Standard Configuration
Protection Degree | Water-proof IP 67, NAMUR 4 and 6, (IP 68 Optional) |
Voltage of Power Supply | 110/220-230V AC/ 1Ph/50/60Hz± 10% 380 / 400/440/V AC/3Ph/50/ 60Hz±10% |
Control Power Supply | 110/220-230V AC/ 1Ph/50/60Hz±10% |
Working Duty (On-off Type) | S2: 10Min~30Min/S4:20~50% |
W o rking Duty (Modulating T y pe) | S4: 30~50%, 300~1,200 Starts/Hour |
Motor | Whole Sealing Squirrel-cage Inductive Motor of F Degree |
Limit Switch | 2 for Each Open/Close Switch (SPDT 250VAC/10A Rating) (More Available ) |
Torque Switch | 1 for Each Open/Close Switch (SPDT 250VAC/10A Rating) (More Available) |
Thermal Protection and Temperature Setting | Thermal Protection Switch Set Inside (Max. 150℃± 5 ℃ , Min97 ℃± 15 ℃ ) |
Stroke | 90°± 5 ° (0 ° ~100 ° ) |
Position Indicator | Continuous Mechanical Position Indication |
Manual Operation Mechanism | Attached |
Self-locking F u nction | Attached |
Mechanical Limit | Attached (External Adjustment Available ) |
Anti-condensation Heater | 5W (110/220-230VA C) |
Cable Interface | 2 PF 3/4 ” |
Ambient Temperature | Basic Type: -20℃ ~+70 ℃ Optional Type: -40 ℃ ~+100 ℃ |
Ambient Humidity | Min. Relative Humidity 10%, Max. R e lative Humidity 100%, No Condensation |
A n ti-shock | XYZ 10g. 02~34Hz, 30 minutes |
Housing | Aluminum Alloy Housing Processed of Hard Anodizing and Polyester Painting |
II. Options
Code | Remark | Note |
EX | Explosive-proof Type | Exd II BT4, BT6, CT4, CT6 |
WT | Watertight Type (IP68) | Continuous work underwater for 100 hours |
ALS | Auxiliary Limit Switch | 4 ones at most |
ATS | Auxiliary Limit Switch | 4 ones at most |
SV | Variable torque and switch speed | Please contact this company before making an order. |
PK | Potentiometer (0~1Kohm) | High precision and integrated design guarantee correct output of valve position |
CT | Current Transformer (Output Signal 4~20mA) | 0 Point and Stroke Adjustable (4-line and 2-line systems for option) |
PCU | Intelligent Central Processing Unit (4~20mA Signal Input and Output) | Intellectualized one-push automatic correction and adjustment function |
LCU | Local Control Unit | Remote control/ open/ stop/ close switch |
LCD | Liquid Crystal Display | Watch the valve position clearly |
LPA | Horizontal Installation | Control air door baffle; Output connecting lever, support and spherical linkage attached |
III. Model Selection Form
